Resolution

0.05% of selected range

Accuracy

±0.5% of full scale of selected range at 25 ℃

TDS

Ranges

(automatic range selection)
k=0.1 Sensor : 0 to 1.000 ppm
                            0 to 10.00 ppm
                            0 to 100.0 ppm
                            0 to 1000 ppm
k=1.0 Sensor : 0 to 10.00 ppm
                           0 to 100.0 ppm
                            0 to 1000 ppm
                            0 to 10.00 ppk
k=10 Sensor : 0 to 100.0 ppm
                          0 to 1000 ppm
                           0 to 10.00 ppk
                           0 to 100.0 ppk

Resolution

0.1% of selected range

Accuracy

±0.5% of full scale of selected range at 25 ℃

pH
Ranges : 0 to 14.00 pH
Resolution : 0.01 pH
Accuracy : ±0.01pH

mV
Ranges : 0 to ±600.0 and
0 to ±1500 mV
(auto-ranging)
Resolution : 0.1 & 1 mV
Accuracy : ±0.15 & ±1 mV

Temperature
Ranges : -10.0 to 120.0 ℃
Resolution : 0.1 ℃
Accuracy : ±0.2 ℃

Input Impedance
>3×1012 Ohms

pH

Automatic(via Temperature sensor) or manual,
0 to 100 ℃.
The labCHEM-CP automatically detects whether or not
the temperature sensor is connected.


Automatic Standard Recognition

Conductivity

14.94 uS/cm, 73.9 uS/cm, 150.0 uS/cm,
717.8 uS/cm, 1413 uS/cm, 2760 uS/cm,
6.67 mS/cm, 12.90 mS/cm, 24.82 mS/cm,
58.00 mS/cm, 111.9 mS/cm

TDS

69.5 ppm, 2.00 ppk, 8.00 ppk, 36.0 ppk

pH
4.00, 6.88, 7.00, 9.23 and 10.06 pH

Enclosure
Tough, high impact ABS. Splash resistant one-piece
lid.

Display
14.5mm high, 16 character alphanumeric LCD with
full-text messages.

RS232 Output(Optional)
300, 1200 and 9600 Baud.
8 Bits, No Parity, 1 stop Bit, XON/XOFF

Recorder Output(Optional)
0 to 2000mV Output for…
0.00 to 14.00 pH
-1500 to 1500 mV
-10.0 to 120.0 ℃
Output impedance approx 1000 Ohms

Power
12V AC/DC Power Adaptor.

Dimensions
270×210 ×75 mm

Mass
Instrument only : Approx 1.0kg
Full Kit : Approx 2.5kg

Environment
Temperature : 0 to 45 ℃
Humidity : 0 to 90% R.H.

Asymmetry Range
-1.00 to +1.00 pH

Slope Range
85.0 to 105.0 %

                                                                     Part No
labCHEM-CP Meter.……………….…..………….126129

Kit Includes

k=1.0/ATC Cond Sensor.….…………..122226
Combination pH Sensor…………………121207
Temperature/ATC Sensor……………..121245

2.76 mS/cm Conductivity

Standard, 200ml………..………………...122306

2.0 ppk TDS Standard

200ml………………………………..………122307
pH6.88 Buffer, 200ml……………………121306
pH4.00 Buffer, 200ml……………………121381
AC/DC Power Adaptor………………….Specify
Country
901-C Handbook………………………..130050

Optional Sensors

IJ pH, 1m…………………………………..121234
(for meat, dairy, slurries etc)
IJ ORP, 1m…………………………………121263
k=10/ATC Cond Sensor………………..122222
k=0.1/ATC Cond Sensor……………….122224
Solution Guard Rod………………………121360

Instrument Options

RS232 Serial Interface…..……………..130029
(includes cable)
Recorder Output………………………….130028
(includes cable)
RS232 PLUS Rec Output……………….130049
(includes cable)

Communication Software

for Windows …...…………………………130086

Flexible Arm Electrode

Holder………………………………………130088
