Specifications

Display:

 Large alphanumeric LCD-4 line, 20 character display

Operation:

Four key splash proof membrane switch-menu driven

Calibration:

NIOSH gravimetric method

Sensing range:

.001-20.0 mg/㎥ .01-200.0 mg/㎥(optional)

Particle size range:

0.1-100um

Precision:

+/-0.003mg/㎥ (3㎍/㎥)

Accuracy:

+/-5% to NIOSH #0600 using ARD

Sampling flow rate:

1.0 - 2.3 liters/minute

Filter cassette:

37mm disposable

Alarm output:

90db at 3ft.

Analog Output:

0-4 vdc

Recording time:

1 sec. to 15 months

Sampling rate:

1sec., 10sec., 1min., and 30min.

Data storage:

21,600 data points

Security code:

4-digit combination

Memory & time storage:

> 10yrs

Real-time clock & data display

Data display:

concentration in mg/㎥ & TWA,MAX,MIN,STEL,DATE,Time

   Optional Equipment

Digital output :

RS-232

Operatingtemperature:

-10℃ to 50℃

Storage temperature:

-20 to 60℃

HAZCOMM software:

WindowsTM driven for graphical and data translation

Power:

Rechargeable battery

Operating time:

≥24 hours

Charging time:

10-12 hours

Humidity:

95% non-condensing

Dimensions(case):

 14.0” x 6.0” x 10.0”

Weight:

12 lbs
