Inlet collection
efficiency :
|
Meets EPA
Methods TO4A, TO9A, TO13A |
Flow rate
: |
280 Liters
per min. (10 CFM) |
Filter media
: |
4"Round
Quartz Filters (TE-QMA4) |
Flow control
: |
Motor Voltage
Control / Elapsed Time Indicator (TE-5010) |
Motor blower |
2 Stage Vacuum
Motor 110v/60hz (TE-116336)
220v/50hz (TE-116125) |
Flow Indicator
: |
0 to 100"Magnehelic
Gage (TE-1005) |
Mechanical
programmable timer : |
7 Day Mechanical
Timer (TE-5007) |
Elapsed time
indicator device : |
Elaspsed
Time Indicator (TE-5010) |
Shipping
Information : |
|
Size
: |
22.5"x
20"x 45.5"sampler carton
14"x 14"x
19"lid carton |
Weight
: |
70 lbs. -
sampler carton |
Assembled
Space Requirement : |
8 lbs. -
lid carton
24"square x 53"high |
Power Requirement |
Single phase
with earth ground
110v/60hz or 220v/50hz
|
Motor Specifications
: |
110v/60hz
- Part #TE-116336, Vaccum, Double Ball
Bearing.
Bypass: Peripheral Discharge
220v/50hz - Part #TE-116125,
Vaccum, Double Ball
Bearing. Bypass: Peripheral
Discharge |
Altitude
Application : |
to
10,000 feet above sea level
|
Ambient Temperature
Application : |
-30 to +50℃ |
Relative
Humidity Application : |
0 - 100% |
Sample Dealy
Start Range : |
0 - 7 days |
Start up
amps : |
12 amps |
Running amps
: |
8 amps |
