Inlet Collection Efficiency :

Meets EPA Code of Federal Regulation
Appendix B to Part 50

Flow rate :

39 cfm - 60 cfm  (1.1 to 1.7 m3)

Filter medial :

Glass Fiber Filter 8"x 10"(TE-G653)

Flow control :

Motor Voltage Control/Elapsed Time Indicator (TE-5010)

Motor blower

2-stage vacuum 0.6 HP
110v/60hz (TE-116311)
220v/50hz (TE-116312)

Flow Indicator :

Flow / pressure recorder (TE-5009)

Mechanical programmable timer :

7-day mechanical timer (TE-5007)

Elapsed time indicator device :

Elapsed time indicator (TE-5010)

Shipping Information :

     Size :

22.5"x 20"x 45.5"sampler carton

     Weight :

65 lbs. - sampler carton

Assembled Space Requirement :

30"round x 64"high

Power Requirement

Single phase with earth ground
110v/60hz or 220v/50hz

Motor Specifications :

110v/60hz - Part #TE-116311, 2-stage vacuum 0.6 HP,
double ball bearing thru-flow discharge
220v/50hz - Part #TE-116312, 2-stage vaccum 0.6 HP,
ball/sleeve bearing thru-flow discharge

Altitude Application :

to 10,000 feet above sea level

Ambient Temperature Application :

-30 to + 50

Relative Humidity Application :

0 - 100%

Sample Delay Start Range :

0 - 7 days

Start up amps :

12 amps

Running amps :

4 amps
